SKU: 98EO 3 26D

Brand : Von Duprin

In Stock

Usually Ships Next Day

×

Transit time is determined by shipping method and destination. Most orders will ship via FedEx or UPS Ground. If an item is out of stock or will require significant lead time we will contact you. Same-Day shipping cutoff time is 12:00 pm EST. Please see our Shipping Info page for more details. You can also CHAT WITH US to determine Shipping Estimates for your specific Items.

$1,399.00
$1,399.00
Finish: US26D - Satin Chrome
Rating: Panic Rated
Subtotal: $1,399.00
Questions? Live Chat, or Call 332-255-3200

Secured and trusted checkout with

Details

Von Duprin 98EO Grade 1 Rim Exit Device, 36" Length, Exit Only

The 98 Series devices are heavy-duty push pads and has a smooth mechanism case. It has been certified to the highest industry standards and are used in schools, hospitals and government buildings.

  • Device lengths: 3' 2'4' to 3' (711mm to 914 mm) Door size
  • Device centerline from finished floor: 39 13/16" (1011 mm) 39 11/16" (1008 mm) with mullion
  • Center case dimensions: 8" x 2 3/4" x2 3/8" (203mm x 70mm x 60mm)
  • Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
  • Projection: Pushbar neutral – 3 13/16" (97 mm) Pushbar depressed – 3 1/16" (78 mm)
  • Latch bolt: Deadlocking, 3/4" (19mm) throw
  • Fasteners & sex bolts (SNB): Includes screw pack for 1 3/4" (44mm) and 2 1/4" (57mm) thick metal or wood doors.
Read more
More Information
Specifications
  • Physical Appearance: Wide Stile Pushpad
  • Device Type: Rim
  • Includes Cylinder(s): No
  • Minimum Stile Size: 4-1/2"
  • Device Length: 36"
  • Door Thickness: 1-3/4" to 2-1/4"
  • Cylinder Type: Non-Keyed
  • Dogging Options: Hex Key Dogging (Fire Rated: Less Dogging)
  • Door Width: 28" to 36"
  • Door Material: Wood or Metal
  • Handing: Non-Handed
  • Includes Trim: No
  • Mechanical Function: Exit Only
  • Trim Design: Blank Plate
