SKU: 1800 x 36 x 689

Brand : ACCENTRA (Formerly Yale)

In Stock

Usually Ships Next Day

×

Transit time is determined by shipping method and destination. Most orders will ship via FedEx or UPS Ground. If an item is out of stock or will require significant lead time we will contact you. Same-Day shipping cutoff time is 12:00 pm EST. Please see our Shipping Info page for more details. You can also CHAT WITH US to determine Shipping Estimates for your specific Items.

$179.65
$179.65
Finish: 689 - Aluminum
Size: 36"
Rating: Panic Rated
Subtotal: $179.65
Questions? Live Chat, or Call 332-255-3200

Quick Overview

  • Designed for wide stile doors
  • Non-handed for simple installation
  • Single and pair door application constructed of Wood, Metal or Composite material
  • Can be paired with a variety of Yale Trims

Secured and trusted checkout with

Details

ACCENTRA 1800 Flatbar Rim Exit Device, Exit Only

The 1800 Series Exit Devices are the ideal choice for economy commercial applications where you need consistent quality, dependability and ease of use and installation. The 1800 Series is ANSI/BHMA certified Grade 1, with durable construction and versatile mounting applications, making it ideal for a variety of facilities. Offering strength and durability in one reliable product after another.

Features:

  • Designed for wide stile doors
  • Non-handed for simple installationteel interlock “E” bracket maintains door-to-mullion relationship in fire-labeled devices
  • Strong & Durable to ensure long life and reliability

Certification/Compliance:

  • ISO 9001 Certification
  • UL-cUL Listed for use on fire doors having a rating up to and including 3-hours
  • ANSI/BHMA A156.23, Grade 1
Read more
More Information
Specifications
  • Door Opening Width:
    • 36 for 30" - 36" (76cm - 91cm) doors
    • 48 for 42" - 48" (107cm - 122cm) doors
  • Door Thickness: 1-3/4" (44mm) standard.
  • Minimum Stile Width: 4-1/2" (114mm)
  • Projection: 2-1/2" (64mm) active, 1-3/4" (44mm) depressed
  • Strike: 757F, 793 optional (double door application)
  • Trims: 210F series utility trim, 420F series escutcheon trim, 440F series rose trim
  • Dogging: Hex key dogging supplied standard on panic devices
UPC 722208643710
