Yale 855FL Grade 1 Mortise Dummy Trim - Single

ACCENTRA (Formerly Yale) 855FL Grade 1 Mortise Dummy Trim - Single

ACCENTRA (Formerly Yale) 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.

Function:

Push or Pull only
Lever one side
Lever non-operational and rigid at all times

Features:

UL Cycle above and beyond test completed at 12.3 Million Cycles. Verification ID: V572228
Heavy-duty trim for resistance against damage and vandalism
Field adjustable lever handing and latchbolt
ANSI/BHMA Certified Grade 1 for long-life and durability
UL/cUL listed for 3 hour fire rated doors

More Information

Specifications	ANSI/BHMA: Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1 UL-cUL: UL/cUL fire rated up to 3 hours Windstorm: Certified (refer to local codes) Mechanism: Stainless steel Backset: 2 3/4" Latchbolt: 3/4" stainless steel throw Door Thickness: 1 3/4" standard, to 3 1/4" thick doors to order Fronts: Bevel front, free-floating to adjust from flat to standard bevel of 1/8" in 2" Cylinders: Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order Reversibility: Field reversible handing Strikes: 1 1/4" curved lip for 1 3/4" door standard; other lip lengths to special order; all reversible Finishes: Available in 17 finishes Warranty: 10 year mechanical
UPC	722208642911

Specifications

ANSI/BHMA: Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
UL-cUL: UL/cUL fire rated up to 3 hours
Windstorm: Certified (refer to local codes)
Mechanism: Stainless steel
Backset: 2 3/4"
Latchbolt: 3/4" stainless steel throw
Door Thickness: 1 3/4" standard, to 3 1/4" thick doors to order
Fronts: Bevel front, free-floating to adjust from flat to standard bevel of 1/8" in 2"
Cylinders: Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
Reversibility: Field reversible handing
Strikes: 1 1/4" curved lip for 1 3/4" door standard; other lip lengths to special order; all reversible
Finishes: Available in 17 finishes
Warranty: 10 year mechanical
